Oxygen Generator/Concentrator:
An oxygen concentrator is a device that concentrates the oxygen from a gas supply (typically ambient air) by selectively removing nitrogen to supply an oxygen-enriched product gas stream.
Medical oxygen concentrators are used in hospitals or at home to produce oxygen for patients. Portable generators provide a cost-efficient source of oxygen. They are a safer, less expensive, and more convenient alternative to tanks of cryogenic oxygen or pressurised cylinders. They can be used in various industries including medical, pharmaceutical production, water treatment and glass manufacture.
Portable generators are particularly useful in remote or inaccessible parts of the world or mobile medical facilities (military hospitals, disaster facilities).
1, discharge range: 1-7L
2. When the oxygen flow is 1L, the oxygen concentration is ≥90%
3, noise: < 60dB(A)
4, power supply: 220V ~ 50HZ
5. Input power: 120W
6, net weight: 6 Kg
Gross weight: 6.5 kg
7, product size: 210X215X305 (mm)
8, altitude: sea level to 1828 meters will not reduce the oxygen concentration, from 1828 meters to 4000 meters when the efficiency is less than 90%
9. Safety system:
Overload current or loose connection will automatically stop
The compressor will stop automatically at high temperature
10. Minimum working time: not less than 30 minutes
11. Working environment:
Ambient temperature range: 5℃ ~ 40℃
Relative humidity: ≤80%
Atmosphere pressure range: 86kPa ~ 106kPa
Note: When the storage and transportation temperature is below 5℃, the equipment should be placed in the normal working temperature environment for more than 4 hours before use
12. Electrical classification: Class II equipment
13. Working system: continuous operation
14. Oxygen outlet temperature ≤46℃
15. Suggestions: The length of the oxygen tube should not exceed 15.2 meters, and it should not be deflated
16, waterproof grade: IPX0
